DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100%

I'm Online Chat Now

DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100%

China DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100% supplier
DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100% supplier DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100% supplier

Large Image :  DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100%

Product Details:

Place of Origin: China
Brand Name: kubota
Certification: ISO9001:2008, CE
Model Number: GNRK
Engine: Kubota
Alternator: Stamford, Leroy somer ,Marathon
Welding current: 500Amp
Rated Power: 24kw
Rated RPM: 1500rpm or 1800rpm
Frequency: 50Hz or 60Hz

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden package
Delivery Time: within 15 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 200 units / month
Contact Now
Detailed Product Description

DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100%





The Kubota diesel engine welder generator is equipped with kubota diesel engine driven welding machines with MMA/TIG/FCAW function, and Strong auxiliary power:15 KW output for three-phase, 6KW output for single-phase.




1. Electric Starter ensures easy starting

2. Separate welding range with fine adjustment in each range

3. Great Welding Performance

4. Auxiliary power while welding

5. 500 Amperes output suitable for 1.6 to 8.0 mm Air Carbon Arc Gouging and Stud Welding

6. Adopts advanced inverter soft switch technology, PWM control technology, and negative feedback control technology,enjoys excellent dynamic quality and welding performance within full voltage/current regulation range.





Model GPW 500 diesel welding generator
Welding output
Welding Processes MMA TIG FCAW
Open Circuit Voltage (V) 75 75 75
Current Range (A) 30-500 30-500 30-500
Welding Current (A) 310 350 500 310 350 500 310 350 500
Welding Voltage (V) 32.4 34 36 22.4 24 26 29.5 31.5 33
Duty Cycle 100% 80% 60% 100% 80% 60% 100% 80% 60%
External Characteristic Curve Drop Characteristic Drop Characteristic Flat Characteristic
Generator output
Power 16Kw
Excitation Type AVR Brushless Excitation
Frequency 50Hz
Phase Three Phase Single Phase
Output Voltage/Power AC 400V/16Kw AC 230V/6.9Kw
Engine
type 4 stroke ,direct injection , water cooled diesel engine
Fuel Diesel
Rated Power 30Kw
Rated Speed 1500 RPM
Low Temperature Pre-heated Start
Warning Type Water Temperature /Oil Pressure/Battery Voltage
Fuel Capacity 50L
Cooling Method Water-cooled
Fuel Consumption 5.0L/hr
Complete appliance





Engine Features:



1. World most famous brand diesel engine: Perkins ,Cummins , Kubota



2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection



3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler



4. Machinery or electronic governing



5. Fuel injection pump



6. Electric motor starting system



7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner



8. Low discharge, and low fuel consumption



9. Installed conveniently and maintain easily





Alternator Features:



1. World famous brand brushless AC alternator



2. Brushless, 4 poles, rotation magnet



3. IP21-23(NEMA1) enclose is standard for all industrial alternators



4. H class insulation system



5. AVR self-regulated, voltage regulation rate:≤±1%



6. Rated Voltage: 127V/220V, 220V/380V, 230V/400V





Control system:



1. Automatic alarm system: the unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current.



2. Operation display:



a) Unit voltage, tri-phase load current and frequency display



b) Water temperature, oil pressure display



c) Fuel level, fuel temperature display



d) Audible and visual alarm lamps and buzzers



DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100%


DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100%
DC Kubota Engine ARC Diesel Welder Generator MMA Duty Cycle: 500A @ 60% 400A @ 100%
