Product Details:

Place of Origin: China
Brand Name: GENOR POWER
Certification: ISO9001:2008, CE
Model Number: NRDML400
Product name: deutz diesel welder genset
Engine type: Deutz air cooled diesel engine
Alternator: Brushless ,AVR self-exciting
Rated Power: 25kw
Welding current: 400amp
Frequency: 50Hz or 60Hz
Engine RPM: 1500rpm or 1800rpm

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden Package / Plywood case
Delivery Time: Within 20 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 200 sets Per Month
Contact Now
Detailed Product Description

400A Deutz F3L912 Engine Welding Machine Genset Diesel Generator For Pipeline Railway Industry



The Deutz air cooled engine diesel welder genset is equipped with air cooled diesel engine driven welding machines with MMA/TIG/FCAW function, and Strong auxiliary power:15 KW output for three-phase, 6KW output for single-phase.





Deutz engine Diesel Welding Genset Features:



1.We Can offer both single position welding machine with MMA/TIG/FCAW function and dual positions welding machine whith MMA plus FCAW function, convenient for customer's choice

2.FCAW meets "filling & covering"welding process,fast,effective,and timesaving,can match Lincoln/Miller wire feeder.Strong auxiliary power: Max 30KW output .

3.Adopts advanced inverter soft switch technology, PWM control technology, and negative feedback control technology,enjoys excellent dynamic quality and welding performance within full voltage/current regulation range.

4.Owns current/voltage parameter preset function,the matched wire feeder can show the preset/real current, also adjust welding current,easy to operate.





Model GPW 500 diesel welding generator
Welding output
Welding Processes MMA TIG FCAW
Open Circuit Voltage (V) 75 75 75
Current Range (A) 30-500 30-500 30-500
Welding Current (A) 310 350 500 310 350 500 310 350 500
Welding Voltage (V) 32.4 34 36 22.4 24 26 29.5 31.5 33
Duty Cycle 100% 80% 60% 100% 80% 60% 100% 80% 60%
External Characteristic Curve Drop Characteristic Drop Characteristic Flat Characteristic
Generator output
Power 16Kw
Excitation Type AVR Brushless Excitation
Frequency 50Hz
Phase Three Phase Single Phase
Output Voltage/Power AC 400V/16Kw AC 230V/6.9Kw
Engine
type 4 stroke ,direct injection , AIR cooled diesel engine
Fuel Diesel
Rated Power 30Kw
Rated Speed 1500 RPM
Low Temperature Pre-heated Start
Warning Type Water Temperature /Oil Pressure/Battery Voltage
Fuel Capacity 50L
Fuel Consumption 5.0L/hr
Complete appliance





Engine Features:



1. Deutz air cooled F3L912 diesel engine:



2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection



3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler



4. Machinery or electronic governing



5. Fuel injection pump



6. Electric motor starting system



7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner



8. Low discharge, and low fuel consumption



9. Installed conveniently and maintain easily





Alternator Features:



1. World famous brand brushless AC alternator



2. Brushless, 4 poles, rotation magnet



3. IP21-23(NEMA1) enclose is standard for all industrial alternators



4. H class insulation system



5. AVR self-regulated, voltage regulation rate:≤±1%



6. Rated Voltage: 127V/220V, 220V/380V, 230V/400V





Control system:



1. Automatic alarm system: the unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current.



2. Operation display:



a) Unit voltage, tri-phase load current and frequency display



b) Water temperature, oil pressure display



c) Fuel level, fuel temperature display



d) Audible and visual alarm lamps and buzzers
