Product Details:

Place of Origin: China
Brand Name: Genor
Certification: ISO9001:2008, CE, CCC
Model Number: GNAW300

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wooden Package / Plywood case
Delivery Time: Within 20 days
Payment Terms: T/T ,L/C ,Western Union, MoneyGram, D/A
Supply Ability: 500/sets per Month
Contact Now
Detailed Product Description
Product Name: 300Amp Diesel Generator Welder Engine Type: 4 Stroke ,Air Cooling Diesel Engine
Welding Current: 60 To 300A Cooling System: Air Cooling
Alternator Type: Rare Earth Permanent Magnet Engine RPM: 1500rpm To 1800rpm
Frequency: 50Hz Or 60Hz Protection Class: IP23
Start System: Electric Start

300Amp Engine Driven Welding machine Diesel Welder Generator AC power 10kva portable





300Amp diesel engine driven welder generator is Arc burning steady, good weld-seam shaping, ease of arcing, less spatter, low voice, high efficiency.



-Adopt intermediate frequency three-phase rectifier, has the advantages of smoothcurrent, good dynamic characteristics,fast response speed (1-3ms). It can meet different welding requirements,and is suitable for all kinds of acid electrode, basic electrode and argon arc welding works.



-Adopt rare earth permanent magnet technology, has the advantages of smaller size, lighter weight, low iron loss and higher efficiency(efficiency up to 90%).



- Abandon the IGBT (insulated gate bipolar transistor) control system, substituted by adopting the "embedded" control mode, which greatly improve the reliability of the control system.





GENERATOR



Model GNAW300
Frequency(HZ) 50 60
Rated.AC voltage(V) 230 240
Rated output(KVA) 3 3.6
Rated speed(rpm) 3000 3600



WELDER




Welding no-load voltage(V) 89V
Working voltage(V) 22-32
Range of current(A) 60 - 300
Welding efficiency 60%
Power factor (cosΦ ) 1
Phase 1



ENGINE


Engine type  2 cylinder,  4-stroke air-cooled diesel engine
Fuel 0# or -10# light diesel fuel
Lubrication oil volume(L) 1.8
Combustion system Direct lnjection
STANDARD FEATURES Voltmeter yes
AC Output Socket 2
AC circuit breaker yes
Oil warning light yes
Oil alert yes





Air Cooling 300Amp Engine Driven Welding Machine AC Power 10kva Portable IP23

Air Cooling 300Amp Engine Driven Welding Machine AC Power 10kva Portable IP23

Air Cooling 300Amp Engine Driven Welding Machine AC Power 10kva Portable IP23
