Product Details:
Place of Origin: China
Brand Name: Ricardo
Certification: ISO9001:2008, CE ,CCC
Model Number: GNR60
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden package / Plywood case
Delivery Time: Within 15 days
Payment Terms: T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability: 200/sets per Month
Detailed Product Description
Product Name: Weifang Ricardo Diesel Generator Parts Engine Brand: Weifang Ricardo
Rating Power: 60kw Alternator: AVR Brushless Self-excited
Starting Method: Electric Auto Start Cooling System: Water Cooling
Frequency: 50Hz Voltage: 220V/380V, 240V/415V
Insulation Class: H Warranty: 12 Months
High Light:

K4100 3 Phase Genset Diesel Generator

,

50Hz Water cooling Genset Diesel Generator

,

60hp Filters Gasket Genset Diesel Generator

Weifang Ricardo r6105 k4100 Engine Spare Parts Genset Diesel Generator 60hp Filters Gasket





1, 20kw ~250kw Ricarod diesel generator

Ricardo diesel engine is basic on the introduction of foreign(Ricardo Britain) advanced diesel engine technology and developed which is characterized by economical fuel consumption,low noise,powerful,stable operation and reliable performance.



2, Main specification

a,3-Phase, 50Hz@1500RPM, 400/230V (Also Can Be Made According To Customers’ Special Requirements)

b,12V/24V DC start motor and storage battery

c,Brushless, Self-excited, IP23, insulation class H alternator

d, 40°C radiator as standard, 50°C is optional

e,Key start panel control system as standard, digital auto-start panel is optional

f,All generator sets are gone through rigorous testing before being released to the market place, including 50% load, 75% load, 100% load, 110% load and all protection function (overspeed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)

5. Wide range of flange adaptors and single bearing disc coupling



Genset Model Prime Powe Standby Power Engine Fuel Consumption Cylinder No. Displacement Bore X Stroke
KW KVA KW KVA (g/kwh) (L ) (mm)
GNRW-28 20 25 22 28 K4100D 236 4 3.6 100*115
GNRW-34 24 30 27 34 K4100D 236 4 3.6 100*115
GNRW-41 30 38 33 41 K4100D 236 4 3.6 100*115
GNRW-55 40 50 44 55 K4100ZD 238 4 3.6 100*115
GNRW-69 50 63 55 69 R4105ZD 238 4 4.3 105*115
GNRW-104 75 94 83 104 R6105ZD 238 6 6.5 105*115
GNRW-125 90 113 100 125 R6105ZLD 238 6 6.5 105*115
GNRW-138 100 125 110 138 R6105AZLD 238 6 6.7 105*115
GNRW-165 120 150 132 165 R6105IZLD 238 6 6.7 105*115
GMRW-206 150 188 165 206 6113AZLD 238 6 7.5 113*115






7. Accessories

1) Standard accessories: Standard 40 radiator mounted on skid, Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, Standard tools kit, operation manual and document.

2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.



Weifang Ricardo R6105 K4100 Engine Spare Parts Genset Diesel Generator 60hp Filters Gasket 0

Weifang Ricardo R6105 K4100 Engine Spare Parts Genset Diesel Generator 60hp Filters Gasket 1
