Product Details:

Place of Origin: China
Brand Name: Perkins
Certification: ISO9001:2008, CE
Model Number: GNRP
Engine: Perkins
Alternator: Stamford, Leroy somer
Control Panel: Smartgen, Deepsea
Rated Power: 250kva
Rated RPM: 1500rpm or 1800rpm
Frequency: 50Hz or 60Hz

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Delivery Time: within 15 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Detailed Product Description
High Light:

perkins power generator

,

perkins generator set

200kw Power plant Soundproof 250kva perkins diesel generator 1306C-E87TAG6 engine AVR



1.The genset canopy can be designed by customers demandfree of charge.

2.Noise level can be designed by customer demand, standard noise level is70-73DB at 7m. Super silent is60-65DB at 7m.

3. Canopy color can be painted free of charge by customer demand. It is high quality paint.

4.All connection components and door lock arestainless steel.

5. We added oil filling inlet withlock

6. The oil boxis separate madeand then welded to the base frame, not by simple welding on the base frame. It is to make sure there is no oil leakage

7. The base frame is withforklift mouthwhich is easy to load and discharge

8. For Logo, we can paint customer's logo when the order is more than 5sets.

9. For technical specification or question, we can support you by ourstrong technical team



Technical parameters of diesel generator sets:
Technical data
Genset Model GNRP250
Prime Power 250KVA
Rated Voltage 400/230V
Frequency 50Hz
Power Factor 0.8(lagging)
Dimension (L×W×H) (mm) 2590*1005*1720
Genset weight (kg) 2135
Diesel Engine
Brand UK Imported
Model 1306C-E87TAG6
Number of Cylinders 6
Total displacement(L) 2.99
Bore (mm)×Stroke(mm) 116.6*135.9
Fuel oil consumption rate g/kw.h 5.7
lubricating oil specification and grade API-CD class above
Fuel oil specification and grade China 0#(Light diesel oil)
Lubricating system force and splash lubricating
Speed adjustment mode Electron
Radiator Introducing advanced technology for high-low water temperature radiator
Alternator
Manufacturer MARATHON Electric Manufacturing Corporation
Brand MARATHON
Alternator Type MP-200-4
Power factor 0.8(Lagging)
Class of insulation H
Degree of protection IP23
Voltage regulation Automatic voltage regulation(AVR)
Sustained Overexcite Time(s) ≥5
Telephone disturbance THF less than 2% TIF less than 50
Machine winding 2/3 pitch
Winding temperature rise H class
