Product Details:

Place of Origin: China
Brand Name: Perkins
Certification: ISO9001:2008, CE
Model Number: GNRP
Engine: Perkins
Alternator: Stamford, Leroy somer ,Marathon,Engga
Control Panel: Smartgen, Deepsea,ComAp
Rated Power: 12kva
Rated RPM: 1500rpm or 1800rpm
Frequency: 50Hz or 60Hz

Payment & Shipping Terms:

Price: Negotiable
Detailed Product Description
High Light:

perkins power generator

,

silent diesel generator

silent perkins engine 12kva diesel generator

Diesel Generator 7kw.jpg

perkins diesel generator set
GEN-SETSModelGNRP10
Engine BrandUK Brand
Rated Output(kw)10
Current(A)14.4
Power factor(cosφ)0.8
Frequency(hz)50/60
Fuel Consumption(g/kw.h)≤252
The regulating rate of instantaneous voltage≤-10%/ +15%
The time of steady voltage≤1.5sec
The waving rate of voltage≤0.5%
The regulating rate of steady frequency≤3%
The regulating rate of instantaneous frequency≤±5%
The time of steady frequency3sec
The waving rate of frequency≤0.25%
Dim L×W×H(mm)1200X700X1100
Weight(kg)300
Diesel engineEngine model403D-15G
Cylinder3
Bore*Stroke(mm)77*81
Lubricating oil capacity4.9
Rated speed(rpm)1500/1800
Cooling methodClosed water cooling
Starting systemElectrical start
Displacement(L)1.5
AlternatorBrandStamford/Marathon/Engga
TypeBrushiess
The connecting way of the phaseThree phases four lines
Insulation degreeH degree
Grading ProtectionIP23

Control system:

a) Automatic alarm system: the unit has the acousto-optics alarm system and

arrestor for any situation asthe start defeat, the water is over temperature, the oil

pulls down, over speed, over load and over current

b) Operation display:

i) Unit voltage, tri-phase load current and frequency display

ii) Water temperature, oil pressure display

iii) Fuel level, fuel temperature display

iv) Audible and visual alarm lamps and buzzers

silent perkins engine 12kva diesel generator 1

silent perkins engine 12kva diesel generator 2silent perkins engine 12kva diesel generator 3
